| Size | ||
| A Overall length | 5.84m | 19ft 2in |
| B Overall width | 2.28m | 7ft 6in |
| C Overall height | 2.55m | 8ft 5in |
| F Wheelbase | 3.07m | 10ft 1in |
| G Min ground clearance | 0.42m | 1ft 4in |
| Performance | ||
| Max lift height | 12.7m | 41ft 8in |
| Rated capacity | 3500kg | 7716lb |
| Lift capacity at max height | 3500kg | 7716lb |
| Max forward reach | 8.73m | 28ft 7in |
| Lift capacity at max reach | 1000kg | 2204lb |
| Weight | 9880kg | 21781lb |
| Max traction force | 82kN | 18434lb |
| Frame leveling angle | ±10° | ±10° |
| Turning radius - outside | 3.8m | 12ft 6in |
| Power | ||
| Engine | Cummins QSF 3.8 L | Cummins QSF 3.8 L |
| Rated power | 74kw55KW(EUⅤ) | 99.2Hp74Hp |
| Max torque | 420Nm | 310lb*ft |
| Cylinder | 4 | 4 |
| Displacement | 3760m | l0.99gal |
| Transmission | Hydrodynamic | Hydrodynamic |
| Max drive speed | 35km/h | 21.75mph |
| Steering | 2WS/4WS/Crab | 2WS/4WS/Crab |
| Tire | ||
| Type | 400/70R24 | 400/70R24 |
| Hydraulic | ||
| Implement pump | Piston pump | Piston pump |
| Hydraulic flow - pressure | 132L/min-270bar | 34.87gal/min-270bar |
| Tank | ||
| Hydraulic tank capacity | 140L | 37gal |
| Fuel tank capacity | 145L | 38.3gal |
| Fork | ||
| Fork size | 1220mm×122mm×50mm | 4ft×4.8in×1.968in |
| Fork rotary | 126° | 126° |
| Working speed | ||
| Boom up/down | 10.2/8s | 10.2/8s |
| Boom extend/retract | 12.7/8s | 12.7/8s |
| Fork lift | 4.6s | 4.6s |
| Fork retract | 4s | 4s |
