Diesel-powered telescopic boom lifts can get the work done at height with super efficiency in large-scale, outdoor constructions and industrial applications.
CE/ANSI/CSA Certified
Parallel four-link lifting mechanism for smooth boom movement
Hexagonal boom design with good anti-fatigue performance and strong rigidity
Smooth leveling and flexible chassis steering
Load sensitive system, saving energy
Upgraded telematics for high efficient service
Deadweight lowering system forsmooth operation and energy efficiency
| Size | ||
| Work Height | 28.7m | 94ft 1in |
| Platform Height | 26.7m | 87ft 7in |
| Horizontal Outreach | 22.1m | 72ft 6in |
| A - Stowed Length | 11.91m | 39ft |
| B - Stowed Width | 2.49m | 8ft 2in |
| C - Stowed Height | 2.82m | 9ft 3in |
| D - Platform Length | 2.44m | 8ft |
| E - Platform Width | 0.91m | 3ft |
| F - Wheelbase | 2.8m | 9ft 2in |
| Tread | 2.49m | 8ft 2in |
| G - Ground Clearance | 0.4m | 1ft 3in |
| Performance | ||
| Platform Capacity (Unrestricted/Restricted) | 300/454kg | 660/1000lb |
| Drive Speed (Stowed) | 5.5km/h | 3.42mph |
| Gradeability | 45% (24°) | 45% (24°) |
| Turning Radius (Inside) | 3.5m | 11ft 5in |
| Turning Radius (Outside) | 6.1m | 20ft |
| Turntable Swing | 360° continuous | 360° continuous |
| Platform Rotation | ±90° | ±90° |
| Tail Swing | 1.75m | 5ft 8in |
| Jib (Range of Articulation) | 130° (-55°~75°) | 130° (-55°~75°) |
| Max. Wind Speed | 12.5m/s | 28mph |
| Power | ||
| Engine | KUBOTA V2607(StageⅤ)/Kubota V3307(Stage III) | KUBOTA V2607(StageⅤ)/Kubota V3307(Stage III) |
| Fuel Tank Capacity | 150L | 39.6 (us gal) |
| Control Voltage | 12V DC | 12V DC |
| Hydraulic Tank Capacity | 150L | 39.6 (us gal) |
| Drive Mode | 4WD | 4WD |
| Steering Mode | Front-whee | Front-wheel |
| Tire | ||
| Type | 385/65-24 solid tire (standard)15-625 foam-filled tire (option)385/55-24.5 foam-filled tire (option) | 385/65-24 solid tire (standard)15-625 foam-filled tire (option)385/55-24.5 foam-filled tire (option) |
| Weight | ||
| Gross | 17400kg | 38360lb |
