Vision Creates Future
Zoomlion telehandler highlights safety and intelligence, featuring stable boom extension, excellent off-road ability and great gradeability.
Comply with CE Standard
Strong power chassis with excellent driving performance and off-road capacity
4×4 drive system, front and rear driving axle with antislip differential gear for great traction force and escape ability
Hydraulic cylinder driven extension system for smooth movement, strong capacity and large work envolope
10.1-inch display screen integrates monitoring, control and entertainment, with a good human-computer interaction experience
Standard floating fork and optional platform, bucket, boom and other attachments meet the diverse needs of customers
| Size | ||
| A Overall length | 4.01m | 13ft 2in |
| B Overall width | 1.83m | 6ft |
| C Overall height | 1.95m | 6ft 5in |
| F Wheelbase | 2.35m | 7ft 8in |
| G Min ground clearance | 0.3m | 1ft |
| Performance | ||
| Max lift height | 6.1m | 20ft |
| Rated capacity | 2500kg | 5510lb |
| Lift capacity at max height | 2000kg | 4410lb |
| Max forward reach | 3.5m | 11ft 6in |
| Lift capacity at max reach | 800kg | 1760lb |
| Weight | 5000kg | 11010lb |
| Max traction force | 73.25kN | 16467lb |
| Frame leveling angle | / | / |
| Turning radius - outside | 3.38m | 11ft 1in |
| Power | ||
| Engine | KUBOTA V3307-CR-TE5 | KUBOTA V3307-CR-TE5 |
| Rated power | 55.4kw | 74.3Hp |
| Max torque | 265Nm | 195lb*ft |
| Cylinder | 4 | 4 |
| Displacement | 3310m | l0.73gal |
| Transmission | Hydrodynamic | Hydrodynamic |
| Max drive speed | 27km/h | 17mph |
| Steering | 2WS/4WS/Crab | 2WS/4WS/Crab |
| Tire | ||
| Type | 12.00-16.5-12PR | 12.00-16.5-12PR |
| Hydraulic | ||
| Implement pump | Gear pump | Gear pump |
| Hydraulic flow - pressure | 88L/min-270bar | 23.3gal/min-270bar |
| Tank | ||
| Hydraulic tank capacity | 100L | 26.4gal |
| Fuel tank capacity | 65L | 17gal |
| Fork | ||
| Fork size | 1220mm×122mm×45mm | 4ft×4.8in×1.77in |
| Fork rotary | 132° | 132° |
| Working speed | ||
| Boom up/down | 7.9/5.2s | 7.9/5.2s |
| Boom extend/retract | 5.7/4.5s | 5.7/4.5s |
| Fork lift | 3.5s | 3.5s |
| Fork retract | 3.5s | 3.5s |
