Electric
ZT14JE

CE/ANSI/CSA Certified

ZT14JE
  • Max. Working Height
    16.6m
    Max.Working Height
  • Platform Capacity
    300/454kg
    Platform Capacity
  • Weight
    8500kg
    Weight
ZT14JE
Specs
Model Example
Size
Work Height 16.6m 54ft5in
Platform Height 14.6m 47ft11in
Horizontal Outreach 12.7m 41ft8in
A - Stowed Length 9.6m 31ft6in
B - Stowed Width 2.28m 7ft6in
C - Stowed Height 2.52m 8ft3in
D - Platform Length 2.44m 8ft
E - Platform Width 0.91m 3ft
Jib Length / /
F - Wheelbase 2.36m 7ft9in
Tread 2.28m 7ft 6in
G - Ground Clearance 0.36m 1ft2in
Performance
Platform Capacity (Unrestricted/Restricted) 300/454kg 660/1000lb
Drive Speed (Stowed) 5.5km/h 3.42mph
Travel speed (stowed) / /
Gradeability 45%(24°) 45%(24°)
Turning Radius (Inside) 2.06m 6ft 9in
Turning Radius (Outside) 4.78m 15ft 8in
Turntable Swing 360° continuous 360° continuous
Platform Rotation ±90° ±90°
Tail Swing 0.9m 2ft 11in
Jib Rotation 130°(﹣55°~75°) 130°(﹣55°~75°)
Max. Wind Speed 12.5m/s 28mph
Power
Battery / /
Charger 48V/40A 48V/40A
Drive Motor 3.3KW 3.3KW
Lifting Motor 10kW 10kW
Auxiliary Power 12V DC 12V DC
Hydraulic Tank 75L 19 gal
Tire
Type Foam-filled tire Foam-filled tire
Weight
Gross 8500kg 18739lb
