Lithium-powered telescopic boom lifts, with 80-volt lithium battery that can be fully charged within 7 hours, are purpose-built for indoor applications with quiet, emission-free and cost-efficient solutions.
CE Certified
| Size | ||
| Work Height | 44m | 144ft 4in |
| Platform Height | 42m | 137ft 10in |
| Horizontal Outreach | 25m | 78ft 1in |
| A - Stowed Length | 16.22m | 53ft 3in |
| B - Stowed Width | 2.47m | 8ft1in |
| C - Stowed Height | 2.86m | 9ft 5in |
| D - Platform Length | 2.44m | 8ft |
| E - Platform Width | 0.91m | 3ft |
| Jib Length | / | / |
| F - Wheelbase | 3.81/4.15m | 12ft 6in/13ft 7in |
| Tread | 2.46/4.14m | 8ft 1in/13ft 4in |
| G - Ground Clearance | 0.4m | 1ft 4in |
| Performance | ||
| Platform Capacity (Unrestricted/Restricted) | 300/454kg | 660/1000lb |
| Drive Speed (Stowed) | 5km/h | 3.1mph |
| Travel speed (stowed) | / | / |
| Gradeability | 45%(24°) | 45%(24°) |
| Turning Radius (Inside) | 6.96/2.15m | 6.96/2.15m |
| Turning Radius (Outside) | 9.26/5.71m | 9.26/5.71m |
| Turntable Swing | 360° continuous | 360° continuous |
| Platform Rotation | ±90° | ±90° |
| Tail Swing | 1.4m | 4ft 7in |
| Jib Rotation | 130°(-55°~75°) | 130°(-55°~75°) |
| Max. Wind Speed | 12.5m/s | 28mph |
| Power | ||
| Battery | 80V/608Ah | 80V/608Ah |
| Charger | 80V /80A | 80V /80A |
| Drive Motor | 5.4kw | 5.4kw |
| Lifting Motor | 30kw | 30kw |
| Auxiliary Power | 12V DC | 12V DC |
| Hydraulic Tank | 250L | 66 gal |
| Tire | ||
| Type | Foam-filled tire | Foam-filled tire |
| Weight | ||
| Gross | 22120kg | 48766lb |
