Powerful chassis with exceptional driving and off-road performance
4×4 drive system with limited-slip differentials on front and rear axles for strong traction and obstacle-crossing capability
10.1-inch display integrating monitoring, control, and entertainment for enhanced human-machine interaction
Enhanced operator comfort—spacious cab, intuitive single joystick, and integrated armrest
Low engine compartment and high boom for all-around visibility; standard reverse camera for greater operational confidence
Precise gravity lowering system for improved energy efficiency
Designed for both European and North
American operating habits for easy adoption by diverse users
Intelligent remote monitoring and rental management platform for quick equipment positioning, fault diagnosis, and operation management
| Size | ||
| A Overall length | 19ft11in | |
| B Overall width | 8ft5in | |
| C Overall height | 8ft4in | |
| F Wheelbase | 11ft5in | |
| G Min ground clearance | 1ft6in | |
| Performance | ||
| Max lift height | 44ft6in | |
| Rated capacity | 10000lb | |
| Lift capacity at max height | 8000lb | |
| Max forward reach | 30ft6in | |
| Lift capacity at max reach | 1500lb/4000lb | |
| Weight | 28109lb | |
| Max traction force | 105kN | |
| Frame leveling angle | ±10° | |
| Turning radius - outside | 14ft6in | |
| Power | ||
| Engine | Cummins F3.8 | |
| Rated power | 121Hp | |
| Max torque | 369ft/lbs | |
| Cylinder | 4 | |
| Displacement | 128 fl oz | |
| Transmission | ZF PowerShife 4F/3R | |
| Max drive speed | 21 mph | |
| Steering | Front wheels/4WS/Crab | |
| Tire | ||
| Type | 14.00-24 | |
| Hydraulic | ||
| Implement pump | Piston pump | |
| Hydraulic flow - pressure | 35.66gal/min280bar | |
| Tank | ||
| Hydraulic tank capacity | 32 gal | |
| Fuel tank capacity | 32 gal | |
| Fork | ||
| Fork size | 4ft×4.8in× 1.968in | |
| Fork rotary | -107-10° | |
| Working speed | ||
| Boom up/down | 13/12s | |
| Boom extend/retract | 15/14s | |
| Fork lift | 6s | |
| Fork retract | 5.4s | |
